720 Flexible Packaging Al - Foil Adhesive Two Component Polyurethane Adhesive

720 Flexible Packaging Al - Foil Adhesive Two Component Polyurethane Adhesive

    • 720 Flexible Packaging Al - Foil Adhesive Two Component Polyurethane Adhesive
    • 720 Flexible Packaging Al - Foil Adhesive Two Component Polyurethane Adhesive
    • 720 Flexible Packaging Al - Foil Adhesive Two Component Polyurethane Adhesive
  • 720 Flexible Packaging Al - Foil Adhesive Two Component Polyurethane Adhesive

    Product Details:

    Place of Origin: China
    Brand Name: Weeton
    Certification: FDA 175.105
    Model Number: 720

    Payment & Shipping Terms:

    Minimum Order Quantity: 200KG
    Price: USD2.2-2.4/KG
    Packaging Details: A: 20KG/bucket B:4KG/bucket
    Delivery Time: 15 days after deposit
    Payment Terms: T/T, L/C
    Supply Ability: 2,000,000Kg/Month
    Contact Now
    Detailed Product Description
    Application: Flexible Packaging Mixing Rate: 20:3 (mass Ratio)
    Solvent: Ethyl Acetate(EA) Color: Colorless To Yellowish
    Material: Polyurethane

    Introduction of 720

    WeetonTM 720 is a two-component PU adhesive for various film/film and film/foil laminates.The product has high initial tack, high bond strength, good transparency, and can effectively prevent the tunnel phenomenon.



    • Properties
    Product Name720 A720 B
    Ingredient-OH-NCO
    Mixing Ratio20:3.5(mass ratio)
    Solid Content72±2%75±2%
    Viscosity4500±500mPa.s2000±1000mPa.s
    SolventEthyl AcetateEthyl Acetate
    Flash Point-4°C-4°C
    ColorYellowishColorless to Yellowish

    • Directions for Use
    • Dilution: Suitable solvent is ethyl acetate, acetone and MEK provided that water content does not exceed 300 ppm. Do not use aromatic or alcoholic solvent.
    • Preparation of Adhesive Mixture: After having added the right quantity of solvent to 720A and having achieved the required solid content, stir 720B into the 720A/solvent mixture.
    • List of dilution:
    720A720BSolventSolid ContentViscosity
    20KG3.5KG14.3KG45%20-24s
    20KG3.5KG19.1KG40%16-19s
    20KG3.5KG25.0KG35%13-16s
    20KG3.5KG33.3KG30%11-15s


    * Viscosity is based on the average viscosity of the Zahn Cup 3# (25°C)

    • Pot life: The ready-for-use adhesive in sealed containers has a working time of about 8 hours. The adhesive should be used up within 4 hours in the laminator. Otherwise, the adhesive should be abandoned, or it may result in unstable laminated film.

    Tropical area (Temperature >28°C + humidity >60%) pot life: Ready-for-use adhesive should be used up within 2 hours.

    • Coating: 720 is suitable for dry lamination with smooth roller or gravure roller. Before mass production, repeated trials should be carried out to determine fitting roller.
    • Coating weight: Depending on the film or foil combination and the end use of the laminates, the adhesive weight may range from 2.5-4.0g/m2 (dry). For printed laminates the weight should be adjusted accordingly, it should be approx.0.5-2g higher than for unprinted films.
    • Drying: The laminator should have good air volume, wind speed, wind pressure and the appropriate temperature to reduce solvent residue. Temperature setting generally follows gradient principle (55°C-65°C, 65°C-75°C, 70°C-85°C). Adjust the temperature of the oven according to the performance of the laminated products, raw materials, process parameters.
    • Pressure adjustment: Appropriate increase in laminating temperature and pressure can improve the bond strength and appearance of the laminates.
    • Curing: Stored in curing chamber (40-50°C), the laminates will be ready for slitting in 24h. The curing time should be extended if the laminates are used for bagging.
    • Film properties: The completely cured 720 is transparent, odorless, elastic and aging-resistant.
    • Product Certification

             720 complies with FDA175.105

    • Storage

    720 has a shelf life of 9 months when stored at a cool and dry place in unopened containers. Once opened, containers of 720 should be sealed tightly again and the product should be consumed within a short period.

    • Packaging Specifications

    720A:20KG/bucket
    720B:3.5KG/bucket

    • Notes

    When using 720 an efficient exhaust hood should be installed to the coating unit due to safety reasons. The exhaust efficiency must be checked prior to production by gas analysis for air isocyanate concentration. Safety regulations with regard to handling of isocyanates have to be followed as per the guidelines issued by the International Isocyanates Institute. Please also refer to the local safety instructions as well as our safety data sheet and contact Huitian for analytical support.
    As the adhesive contains polyisocyanates any contact with skin has to be removed.

    • Others

    Film additives-particularly the types and content of slip agent in LDPE,MDPE and CPP films, film thickness, packed goods, printing inks, pre-treatment and film coating are of significant importance to the end use of the laminates and may affect the performance properties either directly or indirectly. Therefore, practical laminating tests as well as checks on the laminates are necessary before going into full scale production.

    • Statement

    The information provided herein, especially recommendations for the usage and the application of our products, is based upon our knowledge and experience. Due to different materials used as well as to varying working conditions beyond our control we strictly recommend carrying out intensive trials to test the suitability of our products with regard to the required processes and applications. We do not accept any liability with regard to the above information or with regard to any verbal recommendation, except for cases where we are liable of gross negligence or false intention.

    Introduction of Huitian
    Established in 1977, Huitian is now one of the biggest adhesive manufacturers in China. There are four manufacturing bases in total, providing high performance adhesives for different industries.

    8720 General Al Foil Adhesive Flexible packaging, Two-Component Polyurethane adhesive, Lamination Adhesive
    Huitian has two fully automatic productions lines and the capacity is 24,000MT/Year just for flexibile packaging adhesives.
    8720 General Al Foil Adhesive Flexible packaging, Two-Component Polyurethane adhesive, Lamination Adhesive
    Huitian's products has been well received by domestic and international end users
    8720 General Al Foil Adhesive Flexible packaging, Two-Component Polyurethane adhesive, Lamination Adhesive
    Besides construction adhesives, Huitian also provides many others kinds of products for different industries, transportation, electronics, photovaltaic, etc.
    8720 General Al Foil Adhesive Flexible packaging, Two-Component Polyurethane adhesive, Lamination Adhesive
    Huitian is your reliable partner and satisfy your need of adhesives!
