3310 (HTU-3312) UV Curing Adhesive / UV cure adhesive glue for glass and plastic

3310 (HTU-3312) UV Curing Adhesive / UV cure adhesive glue for glass and plastic

3310 (HTU-3312)  UV Curing Adhesive / UV cure adhesive glue for glass and plastic

Product Details:

Place of Origin: CHINA
Brand Name: HUITIAN
Certification: SGS
Model Number: 3310

Payment & Shipping Terms:

Minimum Order Quantity: 60 kg
Price: USD 50
Packaging Details: 1kg/bucket,12 bucket/carton
Delivery Time: 15 DAYS
Payment Terms: L/C,T/T
Supply Ability: 10 TONS MONTH
Contact Now
Detailed Product Description
Color: Amber Component Of Basic Materials: Modified Acrylate
Density: 1.05 Viscosity: 200-400
Curing Energy (mj/cm2): 800 Full Curing Time: 40 Second
Shear Strength: 12 Hardness: Shore D 58
Water Absorption (24h,25℃): 1.8 Glass State Temperature: 50
Stainless Steel /PP Drawing Strength: 5.8 Kg Work Temperature: -50-150

3310 (HTU-3312) UV curable adhesive, low viscosity, UV curable adhesive for glass, plastic, and meta



Product Features:

3310 (HTU-3312) UV curable adhesive is single component, low viscosity, UV curable adhesive for glass, plastic, and metal bonding, suitable for mechanical dispenser. Medical certification passed ISO-10993.

Item Unit Typical Value
Color Component A   Amber
Component of Basic Materials   Modified acrylate
Density Component A g/cm3 1.05
Viscosity Component A mPa*s 200-400
Curing energy (mj/cm2)   800
Handing Curing Time min
Initial Curing Time hour
Full Curing Time second 40
Tensile Strength After Curing Mpa 0
Shear strength % 12
Hardness Shore D 58
water absorption (24h,25℃) (%) 1.8
glass state temperature (℃) 50
Stainless steel /PP drawing strength Kg 5.8
Work Temperature -50-150



Typical use

Adhesive plastic and metal bonding, recommended for disposable injection needle.



Direction for use

The glued material surface should be dry, no oil.

When applied to the adhesive curing light intensity is not lower than 40mW/cm2, was applied to the surface coating time strength of not less than 100mW/cm2.



Matters need attention

Keep it away from children. Ø

Use it in ventilated places

In case of contact with skins, wipe and then flush with clear water.

In case of contact with eyes, flush with clear water immediately and go to hospital for checking.



Package

1kg/Bucket, 12 Bucket/Carton

Storage

Store it in dry and shady places at the temperature of 8~28℃

Storage period is 12 months
