RoomTemperature Use AB Glue For bonding the assembly of automotive materials

RoomTemperature Use AB Glue For bonding the assembly of automotive materials

    • RoomTemperature Use AB Glue For bonding the assembly of automotive materials
    • RoomTemperature Use AB Glue For bonding the assembly of automotive materials
    • RoomTemperature Use AB Glue For bonding the assembly of automotive materials
    • RoomTemperature Use AB Glue For bonding the assembly of automotive materials
  • RoomTemperature Use AB Glue For bonding the assembly of automotive materials

    Product Details:

    Place of Origin: Hubei, China
    Brand Name: Huitian
    Model Number: New Partner

    Payment & Shipping Terms:

    Minimum Order Quantity: 12000 sets
    Price: 0.17-0.21USD/Set
    Packaging Details: 20g/box, 300boxes/carton
    Delivery Time: 12-25 days
    Supply Ability: 8,000,000 sets
    Contact Now
    Detailed Product Description
    Appearance: A-Red, B-Green Mixing Ratio: 1:1
    Curing Type: Room Temperature Curing Positioning Time: 5-8 Minutes
    Tensile Shear Strength: >=18Mpa Packages: 20g/box, 300boxes/carton

    New Partner AB Glue has cured at room temperature fast and can be directly bonded slightly oily surface, repairing leaking oil tank parts, tanks, pipes, flanges, transformers, heat sinks and other equipment. Can also be used for metal, ceramic, plastic, wood and mutual self-adhesive sticky.



    Typical Usage

    For bonding the assembly of automotive plastic panels, lamps, electrical housing, elevators, electrical and other industrial products.



    Technical Data

    Properties before Curing
      A B
    Appearance Red Green
    Mixing Ratio 1 1
    Properties after Curing
    Curing Type

    Room Temperature Curing

    ≥1.0

    Positioning time (25 ℃) 5 ~ 8min
    Temperature ranges -55 ~ 120 ℃
    The maximum thickness of 0.2mm filling

    Tensile shear strength

    (Aluminum - aluminum)

    ≥18MPa
    Impact strength ≥1.0J / cm2
    180o peel strength

    ≥2.3 N / mm





    Precautions
    the product has acrylic glue characteristic pungent odor, which should be used with adequate ventilation.
    This product’ chemical reaction occurred after mixing intensely, the gel’s amount should not be too much, according to the amount of usage once the gel is preferably 2 ~ 20g.
    This product curing speed, should be used first piece is ready to be bonded, and construction should be completed after the gel is positioned within 3 to 5 minutes. This product is a two-component product, unused plastic cap should be covered seal, A and B plastic cap cannot be covered in a wrong way.
    Avoid contact of children eating the product.
    Safety precautions for this product, please consult the product safety data (MSDS).



    Application Guide
    Clean all surfaces to remove oil, impurities, dried, glue AB new partner by volume of 1: 1 mix, spread evenly on being glued pieces, positioning and applying acupressure 8 to 10 minutes to reach the positioning strength, 2 hours You can reach more than 70% strength, 24 hours to complete the cure.



    Storage conditions
    This product should be in a cool, dry warehouse storage, avoid direct sunlight, the best temperature is 8 ℃ ~ 25 ℃. Unused glue should be sealed, so then the next. Highly contaminated glue bottle can reload the original packaging, so as not to affect the performance of the bottle remaining glue.



    Announcements

    Keep away from children.

    If product touch your eyes carelessly, wipe your eyes with cloth before curing, then wash with water.

    If product touches your skin carelessly, flush with water immediately. We suggest using it in a place

    with good ventilation. The product’s safety data please read MSDS as reference.



    Packing specification

    80g/box, 100 boxes/carton.

    20g/pack, 100packs/carton

    20g/box, 300boxes/carton
