1.34g/Cc High Heat RTV Silicone Gasket Maker For Transmission Gear

1.34g/Cc High Heat RTV Silicone Gasket Maker For Transmission Gear

1.34g/Cc High Heat RTV Silicone Gasket Maker For Transmission Gear

Product Details:
Place of Origin: Hubei, China
Brand Name: Jiuwang
Certification: None
Model Number: Black Jiuwang586
Detail Information
Place of Origin:
Hubei, China
Brand Name:
Jiuwang
Certification:
None
Model Number:
Black Jiuwang586
Density:
1.34g/cc
Material:
RTV Silicone
Color:
Black
Hardness:
Shore A 32
Tack-free Time:
18 Mins
Temperature:
-60 ℃ ~ 300 ℃
Scope Of Application:
Engine Oil Pan, Transmission Gear Cover, Axles
Properties:
Anti-aging, Weathering, Heat, Will Not Harden, Shrink Or Crack
High Light:
high heat RTV Silicone Gasket Maker , 1.34g/cc RTV Silicone Gasket Maker , transmission gear rtv silicone caulk
Trading Information
Minimum Order Quantity:
2000 Units
Price:
Negotiation
Packaging Details:
55g/pack, 100pcs/carton 95g/pack, 80packs/carton
Delivery Time:
10-25 days
Supply Ability:
5,000,000pcs
Product Description

RTV Black Silicone gasket maker, High temp rtv silicone gasket maker ,High performance rtv black silicone sealant



Red Longwang gasket maker products back after contact with moisture-cured to form a silicone rubber gasket having flexibility. The product has anti-aging, weathering, heat, will not harden, shrink or crack and other properties. It is mainly used engine oil pan, transmission gear cover, axles and other parts of the bonding and sealing. This product is suitable for a temperature range of -60 ℃ ~ 300 ℃



Typical Usage

This product is not binding limit the size and shape of the face, can replace a variety of rubber, asbestos mat, cork pad and paper pad, to the flange of the automobile, motorcycle engines, gear boxes, axles and various machinery and equipment combined with the implementation of the sealing surface.



Technical Data

Properties before Curing
  Typical Value Limits
Density(25℃),g/cc 1.34 1.3~1.4
Viscosity’s 24 10~30

Mobility, mm;

3min,25℃

7 ≤10
Odor   No odor

Tack-free Time, min:

(Curing Condition: temperature 25℃,50±5%RH)

14 10~30min
Properties after Curing
Tensile Strength, N/mm2 1.25 ≥1.0
Tensile Strength, % 240 150~300
Hardness shore A 35 30~40



How to Use:

1.with cotton and organic solvent to be sealed remove surface oil and impurities.

2.the plastic tube in a suitable whole cut beak, with the glue gun glue to end faces to be sealed, and allowed to form a continuous plastic ring.

3.close two seal faces and secured with bolts.

4.one hour early solid, at 25 ℃, 50% humidity, fully cured within 24 hours. In cooler or dry conditions takes a long time to cure.

5.sealed hose sealant remaining can be used until the next one.



Storage:

Storage In a cool dry place for one year shelf life.



Packaging

55g/pack, 100pcs/carton

85g/pack, 80packs/carton
