9506 One Component Pre Curing Type Thermal Gel Pre Curing System For Easy Dispensing

9506 One Component Pre Curing Type Thermal Gel Pre Curing System For Easy Dispensing

9506 One Component Pre Curing Type Thermal Gel Pre Curing System For Easy Dispensing
  • 9506 One Component Pre Curing Type Thermal Gel Pre Curing System For Easy Dispensing
  • 9506 One Component Pre Curing Type Thermal Gel Pre Curing System For Easy Dispensing
  • 9506 One Component Pre Curing Type Thermal Gel Pre Curing System For Easy Dispensing

9506 One Component Pre Curing Type Thermal Gel Pre Curing System For Easy Dispensing

Product Details:
Place of Origin: CHINA
Brand Name: HUITIAN
Certification: RoHS
Model Number: 9506
Detail Information
Place of Origin:
CHINA
Brand Name:
HUITIAN
Certification:
RoHS
Model Number:
9506
Physical Form:
Paste
Color:
Blue
Density:
3.3 G/cm³
Extrusion flow Rate:
20 G/min
Volume Resistivity:
1.0*10^12 Ω∙cm
Dielectric Strength:
6.0 KV/mm
Thermal Conductivity:
6 W/(m•K)
High Light:
9506 Gel Pre Curing System , Easy Dispensing Gel Pre-Curing System , Thermal Gel Pre Curing System
Trading Information
Minimum Order Quantity:
200 kg
Price:
Negotiation
Packaging Details:
30cc/tube; 300cc/cartridge
Delivery Time:
5-8 days
Payment Terms:
L/C, T/T
Supply Ability:
2000T/Month
Product Description


9506 One-Component Pre-Curing Type Thermal Gel, which has excellent chemical and mechanical stability.



Product Description

  • One-part silicone thermal conductive gel
  • Blue paste
  • Pre-curing type



Product Features:

  • Thermal conductivity: 6.0 W/ m·K
  • Pre-curing system for easy dispensing
  • Excellent chemical and mechanical stability
  • No residual stress after gluing, effectively protects precision electronic components from damage



Technical Parameters

Reference standard Item Unit Value
ASTM D792 Density g/cm3 3.3±0.3
Huitian test method

Flow velocity

(30cc EFD/ 90psi/60s)

 g/min 30
ASTM D257 Volume resistivity Ω·cm 1.0×1012
ASTM D149 Dielectric strength Kv/mm 4
ISO22007 Thermal conductivity W/ m·K 6.0±10%
  Operating temperature ℃ -40~150



Main Applications:

  • Bare die chip low-stress mounting environment
  • 5G communication board cooling field
  • High-value boards need to be reworked

  • Smart phone modules and consumer electronics etc



Packing:

30cc/tube; 300cc/cartridge



Storage:

Store at 8-25°C in a cool and dry place.

Shelf life is 6 months.



9506 One Component Pre Curing Type Thermal Gel Pre Curing System For Easy Dispensing 0
