5272 Two Component Thermal Gel Gap Filler Working Temperature Range -40℃~200℃ Excellent Insulation Performance

5272 Two Component Thermal Gel Gap Filler Working Temperature Range -40℃~200℃ Excellent Insulation Performance

5272 Two Component Thermal Gel Gap Filler Working Temperature Range -40℃~200℃ Excellent Insulation Performance
  • 5272 Two Component Thermal Gel Gap Filler Working Temperature Range -40℃~200℃ Excellent Insulation Performance
  • 5272 Two Component Thermal Gel Gap Filler Working Temperature Range -40℃~200℃ Excellent Insulation Performance
  • 5272 Two Component Thermal Gel Gap Filler Working Temperature Range -40℃~200℃ Excellent Insulation Performance

5272 Two Component Thermal Gel Gap Filler Working Temperature Range -40℃~200℃ Excellent Insulation Performance

Product Details:
Place of Origin: CHINA
Brand Name: HUITIAN
Certification: RoHS
Model Number: 5272
Detail Information
Place of Origin:
CHINA
Brand Name:
HUITIAN
Certification:
RoHS
Model Number:
5272
Physical Form:
Paste
Color Part A:
White
Color Part B:
Blue
Density PartA:
2.8 G/cm³
Density PartB:
2.8 G/cm³
Viscosity Part A:
100 MPa·s
Viscosity Part B:
100 MPa·s
Mixing Ratio:
1:1
Opearting Time @25 °C:
4h
Curing Time @80℃:
30mins
Curing Hardness (Shore 00):
50
Volume Resistivity:
1.0*10^12 Ω∙cm
Dielectric Strength:
8 KV/mm
Thermal Conductivity:
2.5 W/(m•K)
High Light:
Excellent Insulation Performance Gel Gap Filler , 2Component Thermal Gel Gap Filler , 5272 Thermal Gel Gap Filler
Trading Information
Minimum Order Quantity:
200 kg
Price:
Negotiation
Packaging Details:
350ml/cartridge; 25kg/barrel
Delivery Time:
5-8 days
Payment Terms:
L/C, T/T
Supply Ability:
2000T/Month
Product Description


5272 is a two-component room-temperature curing silicone gel, that has high thermal conductivity and low density, good weather resistance, and aging resistance.



Product Description

  • Two-component room-temperature curing silicone gel
  • 1:1 heat curing





Product Features:

  • High thermal conductivity
  • Excellent insulation properties
  • Good weather and aging resistance
  • Flame retardant grade: up to UL94V-0
  • Working temperature: -40°C~200°C
  • RoHS Directive





Technical Parameters

Reference standard Item Unit Value
Properties before curing (25±2℃, 60±5%RH)
Q/HTXC 2 Appearance (A) -- White paste
  Appearance (B) -- Blue paste
GB/T 2794 Viscosity (A) Pa·s 80-160
  Viscosity (B) Pa·s 80-160
GB/T13354 Density (A) g/cm3 2.8±0.1
  Density (B) g/cm3 2.8±0.1
Curing properties (A:B=1:1)
Q/HTXC 2 Curing time (80℃) min 30
Q/HTXC 2 Initial curing time (25℃) min 240
Properties after curing (25±2℃, 60±5%RH)
GB/T531 Hardness Shore 00 40~60
ASTM D149 Dielectric strength KV/mm 7
ASTM D150 Dielectric constant / 5
ISO 22007 Thermal conductivity W/m·K 2.5±10%
US EPA8270E D3-D10 Ppm ＜1,000



Main Applications:



  • New energy vehicle lithium battery
  • Automobile electronic equipment
  • Large storage devices
  • Communication equipment board



Packing:

350ml/cartridge; 25kg/barrel



Storage:

Store at 8-25°C in a cool and dry place.

Shelf life is 6 months.
