3312 Series (HTU-3312) UV Curing Adhesive for glass , plastic , metal bonding

3312 Series (HTU-3312) UV Curing Adhesive for glass , plastic , metal bonding

3312 Series (HTU-3312) UV Curing Adhesive for glass , plastic , metal bonding

Product Details:
Place of Origin: China
Brand Name: Huitian
Certification: ISO
Model Number: 3312
Detail Information
Place of Origin:
China
Brand Name:
Huitian
Certification:
ISO
Model Number:
3312
Name:
3312 Series (HTU-3312) Of UV Adhesive
Component A:
1.05 G/cm3
Curing Energy (mj/cm2):
800
Full Curing Time:
40 Seconds
Shear Strength:
12 %
Hardness:
58 Shore D
Water Absorption (24h,25℃):
1.8 %
High Light:
glass and metal glue , plastic to glass adhesive
Trading Information
Minimum Order Quantity:
1000 pics
Price:
Negotiation
Packaging Details:
1kg/bucket, 12 bucket/Carton
Product Description

3312 Series (HTU-3312) of UV adhesive. low viscosity, for glass, plastic, and metal bonding, suitable



Product Features:

3312 Series (HTU-3312) UV curable adhesive is single component, low viscosity, UV curable adhesive for glass, plastic, and metal bonding, suitable for mechanical dispenser. Medical certification passed ISO-10993.

Item Unit Typical Value
Color Component A   Amber
Component of Basic Materials   Modified acrylate
Density Component A g/cm3 1.05
Viscosity Component A mPa*s 200-400
Curing energy (mj/cm2)   800
Handing Curing Time min
Initial Curing Time hour
Full Curing Time second 40
Tensile Strength After Curing Mpa 0
Shear strength % 12
Hardness Shore D 58
water absorption (24h,25℃) (%) 1.8
glass state temperature (℃) 50
Stainless steel /PP drawing strength Kg 5.8
Work Temperature -50-150



Typical use

Adhesive plastic and metal bonding, recommended for disposable injection needle.



Direction for use

The glued material surface should be dry, no oil.

When applied to the adhesive curing light intensity is not lower than 40mW/cm2, was applied to the surface coating time strength of not less than 100mW/cm2.



Matters need attention

Keep it away from children.

Use it in ventilated places

In case of contact with skins, wipe and then flush with clear water.

In case of contact with eyes, flush with clear water immediately and go to hospital for checking.



Package

1kg/Bucket, 12 Bucket/Carton

Storage

Store it in dry and shady places at the temperature of 8~28℃

Storage period is 12 months
